SEAES T54
Seaes T54 waterproof LED luminaire, surface mounted, intended to illuminate the technical rooms of marine vessels, as well as open decks of river vessels. It is used for general and/or emergency lighting. It can be installed on vessels with additional sign “Winterization –40”.
Seaes T54 waterproof LED luminaire, surface mounted, intended to illuminate the technical rooms of marine vessels, as well as open decks of river vessels. It is used for general and/or emergency lighting. It can be installed on vessels with additional sign “Winterization –40”.
Seaes T54 waterproof LED luminaire, surface mounted, intended to illuminate the technical rooms of marine vessels, as well as open decks of river vessels. It is used for general and/or emergency lighting. It can be installed on vessels with additional sign “Winterization –40”.
• 110/240 V or 24 V
• Lumination flux: up to 5000 lm
• LED
• IP67
• Temperature: -40°С ... + 45°С
• Integrated rechargeable battery lasting for 3 hours
High-quality components of luminaires: powder coated body made of galvanized steel, impact-resistant transparent polycarbonate globe, vibration-proof marine grade LED module with an opal diffuser, AISI316 stainless steel clips. It can be equipped with an integrated battery pack able to last for 3 hours and with a second lighting circuit.
TECHNICAL DETAILS
VOLTAGE:
• 220–240 V, 50–60 Hz
• 12–24 V, 0 Hz
POWER AND LUMINOUS FLUX:
• 2 × 11 W – 1950 lm
• 2 × 13 W – 2848 lm
• 2 × 17 W – 4128 lm
• 4 × 7 W – 2848 lm
COLOR TEMPERATURE:
• 4000 K; CRI > 80; MacAdam – 3
TEMPERATURE AND IP:
• –40 °C ... +45 °C; IP67
LED LIFE TIME:
• 50,000 hours
BODY:
• Painted galvanized steel
CONNECTION:
• 3 × 2.5 mm² (standard)
• 5 × 2.5 mm² (for versions with emergency lighting kit and for versions with brightness control)
• 5 × 6.0 mm²; cable for pass through 5 × 2.5 mm² (optional)
LENS:
• Globe made of impact-resistant (IK10) transparent polycarbonate – PC
• Optional anti-glare diffuser – OP
CABLE GLANDS:
• Polyamide M20 for Ø 7–14 mm cable
• Brass B20 for Ø 6–13 mm cable
• Polyamide M25 for Ø 9–17 mm cable (optional)
• Brass B25 for Ø 9–17 mm cable (optional)
INSTALLATION:
• Universal bracket at the ends of the luminaire with two holes Ø 10.0 mm
• Custom brackets are available:
• M10 bolt
• Cross bar
• Bracket for the pipe
• Anti-vibration bracket
