• 110/240 V or 24 V
• Lumination flux: up to 2000 lm
• LED
• IP44
• Integrated rechargeable battery lasting for 3 hours
The components of the luminaires are made of high-quality materials: powder coated body made of galvanized steel, impact-resistant polycarbonate cover, vibration-proof marine grade LED module, double-pole waterproof switch, splash-proof power socket.
Intended for local lighting in toilets and cabins. It can be used as a table luminaire.
TECHNICAL DETAILS
VOLTAGE:
• 220–240 V, 50–60 Hz
• 12–24 V, 0 Hz
POWER AND LUMINOUS FLUX:
• 1 × 13 W – 1400 lm
• 1 × 17 W – 2000 lm
• 2 × 7 W – 1400 lm
COLOR TEMPERATURE:
• 4000 K; CRI > 80; MacAdam – 3
TEMPERATURE AND IP:
• 0ºC...+45ºC; IP44
LED LIFE TIME:
• 50,000 hours
BODY:
• Painted galvanized steel
LENS:
• Impact-resistant opal polycarbonate – PC
CONNECTION:
• 3 × 2.5 mm² (standard)
CABLE GLANDS:
• Membrane grommet for Ø 7–14 mm cable
MOUNTING:
• Four mounting holes Ø 5.5 mm on the back wall of the luminaire
